ترانسمیتر دما TXRAIL-USB NOVUS

توضیحات محصول

TxRail-USB is a USB configurable DIN rail mount temperature
transmitter. It allows selection and configuration of input type,
measurement range, output type and calibration. Its output can
be set to either loop powered 4-20mA or 0-10V. Highly accurate
and user-friendly, the TxRail-USB performs well from simple to
sophisticated measurement applications

Features
 Universal input accepts Thermocouples J, K, T, E, N, R, S, B,
Pt100, Pt1000, NTC and 0-50 mV
 Configurable measurement range
 Sensor break detection according to NAMUR Ne43
recommendations
 Internal cold junction compensation
 Pt100/Pt1000 connection for 2, 3 and 4 wires
 Accuracy (@ 25 °C): typical 0,1% of span for thermocouple, mV,
Pt100 and Pt1000
 Temperature effect <± 0,16% @ 25º C
 Configurable output to 4-20 mA loop powered or 0-10 V.
 Output Linearized according to measured temperature
 Output resolution: 4-20 mA output: 2 μA
0-10 V output: 2,5 mV
 Power supply: 10 to 35 Vdc (4-20 mA output)
12 to 30 Vdc (0-10 Vdc output)
 Operating temperature: -40 to 85 °C
 Free Windows® configuration software
 USB micro-B port allows direct PC connection for configuration.
USB Class CDC
 Dimensions: 99,5 x 114 x 12,5 mm

Configuration Software

The USB port makes configuration easy. By using an ordinary USB
Micro-B cable and NOVUS free configuration software the
Transmitter can be totally configured and calibrated.
The TxConfig II software, required to communicate with the
TxRail-USB is available for download at
www.novusautomation.com.
